HBT40（07） 型號model | ||||
|
性能general |
牽引力(搬運量)traction force |
kg |
4000 | |
|
行駛速度travel speed |
滿載load |
km/h |
8 | |
|
無負荷unloaded |
km/h |
10 | ||
|
最小轉彎半徑turning radius |
mm |
1565 | ||
|
一般規格size |
長度length |
mm |
2050 | |
|
寬度width |
mm |
1100 | ||
|
高度lift |
mm |
1400 | ||
|
軸距wheelbase |
mm |
1200 | ||
|
輪距(后輪)wheel tread® |
mm |
900 | ||
|
總重weight/unload |
kg |
1250 | ||
|
電器裝置electric cquipment |
功率power |
kw |
2.7 | |
|
電瓶battery |
電壓voltage |
v |
48 | |
|
容量amphere |
ah/5hr |
280 | ||
|
充電器charger |
充電電源power supply |
380V | ||
|
充電方式 |
|
額定電流,定電壓 | ||
|
控制方式brake type |
. |
S.E.M | ||
|
輪胎wheels |
前輪forword |
|
305×127(1) | |
|
后輪rear |
|
400-8(2) | ||
